Wide Flange Tapered Plastic Plug Caps

 800.633.6775


Wide Flange Tapered Plastic Plug Caps

WF


Wide Flange Plastic Hole Stoppers
Wide Flange Tapered Plastic Plug Caps

WF–Media

Wide Flange Plug Caps Wider Flange Plug Cap Tapered plug caps Wide Flange Plug Caps Tapered Caps and Plugs with Wide Flanges Wide Flange Plastic Hole Stoppers Plastic Stoppers with Wide Flange Plastic End Caps with Wider Brim
  • Material: LDPE (Low Density Polyethylene) (Red)
  • Featuring a Wider Flange than the T Series for Added Protection of External Surfaces

Size Chart Tapered plug caps

WF Size Chart

Table View
List View
Part # Description Small O.D.
in
mm
 Large O.D.
in
mm
 Small I.D.
in
mm
 Large I.D.
in
mm
 Length
in
mm
 Flange OD
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
WF.173/.240 Wide Flange Tapered Plastic Plug Caps - WIDER FLANGE TAPERED PLUG CAP, LDPE
0.173
4.4
0.240
6.1
0.111
2.8
0.177
4.5
0.380
9.7
0.560
14.2
 5000 1000 100
WF.240/.315 Wide Flange Plastic End Plugs - WIDER FLANGE TAPERED PLUG CAP, LDPE
0.240
6.1
0.315
8.0
0.183
4.6
0.245
6.2
0.360
9.1
0.620
15.7
 5000 1000 100
WF.302/.375 Plastic End Caps with Wider Brim - WIDER FLANGE TAPERED PLUG CAP, LDPE
0.302
7.7
0.375
9.5
0.240
6.1
0.303
7.7
0.380
9.7
0.690
17.5
 5000 1000 100
WF.360/.425 Plastic Stoppers with Wide Flange - WIDER FLANGE TAPERED PLUG CAP, LDPE
0.360
9.1
0.425
10.8
0.298
7.6
0.363
9.2
0.380
9.7
0.750
19.1
 5000 1000 100
WF.425/.480 Wide Flange Plastic Hole Stoppers - WIDER FLANGE TAPERED PLUG CAP, LDPE
0.425
10.8
0.480
12.2
0.363
9.2
0.418
10.6
0.380
9.7
0.810
20.6
 5000 1000 100
WF.472/.540 Tapered Caps and Plugs with Wide Flanges - WIDER FLANGE TAPERED PLUG CAP, LDPE
0.472
12.0
0.540
13.7
0.410
10.4
0.478
12.1
0.440
11.2
0.880
22.4
 5000 1000 100
WF.536/.615 Wide Flange Plug Caps - WIDER FLANGE TAPERED PLUG CAP, LDPE
0.536
13.6
0.615
15.6
0.474
12.0
0.553
14.0
0.440
11.2
0.940
23.9
 5000 1000 100
WF.590/.670 Tapered plug caps - WIDER FLANGE TAPERED PLUG CAP, LDPE
0.590
15.0
0.670
17.0
0.528
13.4
0.608
15.4
0.500
12.7
1.000
25.4
 5000 1000 100
WF.643/.726 Wider Flange Plug Cap - WIDER FLANGE TAPERED PLUG CAP, LDPE
0.643
16.3
0.726
18.4
0.581
14.8
0.662
16.8
0.500
12.7
1.030
26.2
 5000 1000 100
WF.683/.785 Wide Flange Tapered Plastic Plug Caps - WIDER FLANGE TAPERED PLUG CAP, LDPE
0.683
17.3
0.785
19.9
0.621
15.8
0.723
18.4
0.530
13.5
1.130
28.7
 5000 1000 100
WF.765/.865 Wide Flange Plastic End Plugs - WIDER FLANGE TAPERED PLUG CAP, LDPE
0.765
19.4
0.865
22.0
0.703
17.9
0.803
20.4
0.560
14.2
1.190
30.2
 5000 1000 100
WF.820/.930 Plastic End Caps with Wider Brim - WIDER FLANGE TAPERED PLUG CAP, LDPE
0.820
20.8
0.930
23.6
0.758
19.3
0.868
22.0
0.590
15.0
1.250
31.8
 5000 1000 100
WF.872/.977 Plastic Stoppers with Wide Flange - WIDER FLANGE TAPERED PLUG CAP, LDPE
0.872
22.1
0.977
24.8
0.810
20.6
0.916
23.3
0.590
15.0
1.310
33.3
 2500 500 50
WF.975/1.10 Wide Flange Plastic Hole Stoppers - WIDER FLANGE TAPERED PLUG CAP, LDPE
0.975
24.8
1.104
28.0
0.913
23.2
1.042
26.5
0.720
18.3
1.440
36.6
 2500 500 50
WF1.15/1.27 Tapered Caps and Plugs with Wide Flanges - WIDER FLANGE TAPERED PLUG CAP, LDPE
1.158
29.4
1.275
32.4
1.096
27.8
1.213
30.8
0.720
18.3
1.560
39.6
 2500 500 50
WF1.17/1.28 Wide Flange Plug Caps - WIDER FLANGE TAPERED PLUG CAP, LDPE
1.175
29.8
1.284
32.6
1.120
28.4
1.229
31.2
0.630
16.0
1.670
42.4
 2500 500 50
WF1.24/1.37 Tapered plug caps - WIDER FLANGE TAPERED PLUG CAP, LDPE
1.243
31.6
1.375
34.9
1.181
30.0
1.313
33.4
0.720
18.3
1.690
42.9
 2500 500 50
WF1.31/1.47 Wider Flange Plug Cap - WIDER FLANGE TAPERED PLUG CAP, LDPE
1.312
33.3
1.475
37.5
1.250
31.8
1.413
35.9
0.880
22.4
1.810
46.0
 1000 200 20
WF1.45/1.61 Wide Flange Tapered Plastic Plug Caps - WIDER FLANGE TAPERED PLUG CAP, LDPE
1.455
37.0
1.615
41.0
1.393
35.4
1.553
39.4
0.720
18.3
1.940
49.3
 1000 200 20
WF1.51/1.60 Wide Flange Plastic End Plugs - WIDER FLANGE TAPERED PLUG CAP, LDPE
1.517
38.5
1.600
40.6
1.432
36.4
1.514
38.5
0.490
12.4
2.260
57.4
 2000 400 40
WF1.57/1.68 Plastic End Caps with Wider Brim - WIDER FLANGE TAPERED PLUG CAP, LDPE
1.575
40.0
1.685
42.8
1.513
38.4
1.623
41.2
0.690
17.5
2.000
50.8
 1000 200 20
WF1.73/1.90 Plastic Stoppers with Wide Flange - WIDER FLANGE TAPERED PLUG CAP, LDPE
1.735
44.1
1.900
48.3
1.673
42.5
1.838
46.7
0.720
18.3
2.220
56.4
 1000 200 20
WF1.81/1.95 Wide Flange Plastic Hole Stoppers - WIDER FLANGE TAPERED PLUG CAP, LDPE
1.810
46.0
1.950
49.5
1.748
44.4
1.888
48.0
0.690
17.5
2.310
58.7
 1000 200 20
WF1.94/2.10 Tapered Caps and Plugs with Wide Flanges - WIDER FLANGE TAPERED PLUG CAP, LDPE
1.945
49.4
2.100
53.3
1.883
47.8
2.038
51.8
0.690
17.5
2.440
62.0
 1000 200 20
Part # Description Small O.D.
in
mm
 Large O.D.
in
mm
 Small I.D.
in
mm
 Large I.D.
in
mm
 Length
in
mm
 Flange OD
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
Legend:
- Add to Cart - View Price

Plug To use as a PLUG:
Select a PLUG with a “B” dimension at least .020” (0.5mm) larger than the diameter to be plugged (increase 1% or more for large diameters)

Cap To use as a CAP:
Select a CAP with a “C” dimension at least .020” (.5 mm) smaller than the diameter to be capped (increase 1% or more for large diameters)

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.
MOCAP vous propose la vente de capuchons de toutes sortes. Ils répondront à vos besoins.

Spécialiste du bouchon en plastique, MOCAP est fabricant de bouchons de protection, MOCAP est fabricant, de bouchons en silicone. Le groupe vous propose l’achat et la vente de bouchons en plastique ainsi que toute une gamme de produits tels que la pastille haute température, le capuchon en vinyle et le ruban autosoudant.



Wide Flange Tapered Plastic Plug Caps - Information

MOCAP Wide Flange Tapered Plastic Plug Caps are inexpensive dual function closures which can be used as either a plug or a cap. These tapered polyethylene plug caps are made from tough, but flexible polyethylene to form a secure fit, yet are easily removed.
These Plastic Plugs feature a wider flange than our standard T Series plug caps, adding protection for external surfaces and preventing the plug from accidentally being pushed all the way into or through an opening.
Recommended to use as a cap for tube and hydraulic fittings, tube end caps, pipe caps or product protection. Or use as a plug for threaded holes, openings, fittings and ports.

  • Durable and Flexible - Use as a Cap or Plug
  • Protects Against Debris, Damage, Moisture and Corrosion
  • MOCAP stocks Wide Flange Tapered Plastic Plug Caps in many sizes for immediate shipment.


Functions as a Cap
MOCAP WF Series Plastic Plug Caps have a tapered design which allow it to be used as a cap for multiple threaded and non-threaded applications.
Review MOCAP's Selection of Caps.

Functions as a Plug
Use MOCAP Tapered Plug Caps to plug a wide range of openings, including threaded and non-threaded holes, pipe and tube end plugs, connector ports and fittings.
Review MOCAP's Selection of Plugs.

Masking Applications
MOCAP Plug Caps can also be used as inexpensive, single use disposable masking caps or masking plugs for painting, coating and spraying processes up to 175°F(79°C).
Review MOCAP's complete Line of Masking Products.

MOCAP stocks Wide Flange Tapered Plastic Plug Caps in many sizes for immediate shipment.


MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.
