Split Hydraulic Flange Plugs

SHF


Plugs for Four-Bolt Split Hydraulic Flanges
Split Hydraulic Flange Plugs

SHF–Media

Split Hydraulic Flange Plugs Plastic Covers for Split-Flange Connections Covers for Split Flange Ports Plastic Inserts for Split Flange Ports Plastic Plugs for Split Flange Connections Plugs for Four-Bolt Split Hydraulic Flanges LDPE Split Flange Port Plugs SAE 3000 lb Split Hydraulic Flanges Split Flange Plugs Split Hydraulic Flange Plugs
  • Material: LDPE (Low Density Polyethylene)
  • Stocked Material: LDPE (Red)
  • Intended for Use on SAE 3000 LB, Four-bolt Split Hydraulic Flanges
  • Designed to Protect the Port, Flange Surface and Bolt Holes from Damage and Debris

Size Chart Covers for Split Flange Ports

SHF Size Chart

Table View
List View
Part # Description To Fit Flange Size To Fit Dash Size Small O.D.
in
mm
 Large O.D.
in
mm
 Flange Width
in
mm
 Flange Height
in
mm
 Length
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
SHF.750 Split Hydraulic Flange Plugs - PLUG FOR 3/4"-12 SPLIT HYDRAULIC FLANGE 3/4” 12
0.730
18.5
0.790
20.1
2.560
65.0
1.620
41.1
0.500
12.7
 2500 500 50
SHF1.000 Split Flange Plugs - PLUG FOR 1"-16 SPLIT HYDRAULIC FLANGE 1 ” 16
0.980
24.9
1.040
26.4
2.750
69.9
1.880
47.8
0.500
12.7
 1000 200 20
SHF1.250 SAE 3000 lb Split Hydraulic Flanges - PLUG FOR 1-1/4"-20 SPLIT HYDRAULIC FLANGE 1-1/4” 20
1.230
31.2
1.290
32.8
3.120
79.2
2.000
50.8
0.500
12.7
 1000 200 20
SHF1.500 LDPE Split Flange Port Plugs - PLUG FOR 1-1/2"-24 SPLIT HYDRAULIC FLANGE 1-1/2” 24
1.460
37.1
1.550
39.4
3.690
93.7
2.380
60.5
0.750
19.1
 500 100 10
SHF2.000 Plugs for Four-Bolt Split Hydraulic Flanges - PLUG FOR 2"-32 SPLIT HYDRAULIC FLANGE 2 ” 32
1.960
49.8
2.050
52.1
4.000
101.6
2.750
69.9
0.750
19.1
 500 100 10
SHF2.500 Plastic Plugs for Split Flange Connections - PLUG FOR 2-1/2"-40 SPLIT HYDRAULIC FLANGE 2-1/2” 40
2.460
62.5
2.550
64.8
4.500
114.3
3.250
82.6
0.750
19.1
 250 50 5
Part # Description To Fit Flange Size To Fit Dash Size Small O.D.
in
mm
 Large O.D.
in
mm
 Flange Width
in
mm
 Flange Height
in
mm
 Length
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
Legend:
- Add to Cart - View Price

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.
MOCAP vous propose la vente de capuchons de toutes sortes. Ils répondront à vos besoins.

Spécialiste du bouchon en plastique, MOCAP est fabricant de bouchons de protection, MOCAP est fabricant, de bouchons en silicone. Le groupe vous propose l’achat et la vente de bouchons en plastique ainsi que toute une gamme de produits tels que la pastille haute température, le capuchon en vinyle et le ruban autosoudant.



Split Hydraulic Flange Plugs - Information

MOCAP Split Hydraulic Flange Plugs are designed for use on SAE 3000 lb., four-bolt split hydraulic flanges allowing for maximum flexibility. Designed to protect the port, flange surface and bolt holes from damage and debris during transit, handling and storage, our SHF series Split Hydraulic Flange Plugs are easy to install and remove.

Our SHF Series parts are molded in red LDPE plastic to fit 3/4-12 thru 2-1/2-40 Nominal Flange sizes.

MOCAP stocks Split Hydraulic Flange Plugs in many sizes for immediate shipment.

MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.
