Thick Extra Wide Flange Tapered Plug Caps

 800.633.6775


Thick Extra Wide Flange Tapered Plug Caps

XW


Polyethylene Plug Caps with Extra Wide Flange
Thick Extra Wide Flange Tapered Plug Caps

XW–Media

Thick Extra Wide Flange Plug Caps Thick Extra Wide Flange Plug Cap Thick Tapered Plastic Caps Tapered Plug Caps with Thick Extra Wide Flange Plastic Tapered Dust Caps Polyethylene Plug Caps with Extra Wide Flange Caps with Extra Wide Flange for Hydraulic fittings and Pipes Plastic Stopers with Extra Wide Brim
  • Material: LDPE (Low Density Polyethylene) (Yellow)
  • Over-Sized Flanges and High-Visibility for Pre-Assembly Operation Removal
  • Featuring a Wider Flange than the TWF Series for Added Protection of External Surfaces

Size Chart Thick Tapered Plastic Caps

XW Size Chart

Table View
List View
Part # Description Small O.D.
in
mm
Large O.D.
in
mm
Small I.D.
in
mm
Large I.D.
in
mm
Length
in
mm
Flange OD
in
mm
Box/Mini/Micro
QTY
Buy Online
More info
XW.628/.725 Thick Extra Wide Flange Tapered Plug Caps - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE
0.628
16.0
0.725
18.4
0.566
14.4
0.643
16.3
0.440
11.2
2.230
56.6
1000 200 20
XW.755/.870 Thick Extra Wide Flange Plastic End Plugs - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE
0.755
19.2
0.870
22.1
0.686
17.4
0.788
20.0
0.500
12.7
2.370
60.2
1000 200 20
XW.867/.975 Plastic Stopers with Extra Wide Brim - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE
0.867
22.0
0.975
24.8
0.798
20.3
0.889
22.6
0.560
14.2
2.480
63.0
1000 200 20
XW.984/1.10 Caps with Extra Wide Flange for Hydraulic fittings and Pipes - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE
0.984
25.0
1.105
28.1
0.909
23.1
1.014
25.8
0.660
16.8
2.610
66.3
1000 200 20
XW1.11/1.25 Polyethylene Plug Caps with Extra Wide Flange - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE
1.110
28.2
1.253
31.8
1.046
26.6
1.171
29.7
0.660
16.8
2.730
69.3
500 100 10
XW1.23/1.38 Plastic Tapered Dust Caps - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE
1.237
31.4
1.382
35.1
1.171
29.7
1.291
32.8
0.660
16.8
2.880
73.2
800 160 16
XW1.31/1.46 Tapered Plug Caps with Thick Extra Wide Flange - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE
1.312
33.3
1.465
37.2
1.243
31.6
1.375
34.9
0.660
16.8
2.970
75.4
800 160 16
XW1.45/1.60 Thick Tapered Plastic Caps - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE
1.452
36.9
1.603
40.7
1.387
35.2
1.519
38.6
0.660
16.8
3.100
78.7
700 140 14
XW1.58/1.71 Thick Extra Wide Flange Plug Cap - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE
1.580
40.1
1.714
43.5
1.513
38.4
1.624
41.2
0.660
16.8
3.210
81.5
700 140 14
XW1.73/1.90 Thick Extra Wide Flange Tapered Plug Caps - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE
1.735
44.1
1.900
48.3
1.673
42.5
1.838
46.7
0.720
18.3
4.000
101.6
700 140 14
XW1.92/2.05 Thick Extra Wide Flange Plastic End Plugs - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE
1.927
48.9
2.058
52.3
1.867
47.4
1.973
50.1
0.660
16.8
3.560
90.4
600 120 12
XW2.12/2.29 Plastic Stopers with Extra Wide Brim - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE
2.120
53.8
2.290
58.2
2.036
51.7
2.210
56.1
1.000
25.4
3.790
96.3
300 60 6
XW2.39/2.60 Caps with Extra Wide Flange for Hydraulic fittings and Pipes - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE
2.395
60.8
2.602
66.1
2.322
59.0
2.530
64.3
1.130
28.7
4.100
104.1
200 40 4
XW2.63/2.79 Polyethylene Plug Caps with Extra Wide Flange - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE
2.638
67.0
2.795
71.0
2.547
64.7
2.670
67.8
1.130
28.7
4.260
108.2
200 40 4
Part # Description Small O.D.
in
mm
Large O.D.
in
mm
Small I.D.
in
mm
Large I.D.
in
mm
Length
in
mm
Flange OD
in
mm
Box/Mini/Micro
QTY
Buy Online
More info
Legend:
- Add to Cart - View Price

Plug To use as a PLUG:
Select a PLUG with a “B” dimension at least .020” (0.5mm) larger than the diameter to be plugged (increase 1% or more for large diameters)

Cap To use as a CAP:
Select a CAP with a “C” dimension at least .020” (.5 mm) smaller than the diameter to be capped (increase 1% or more for large diameters)

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.
MOCAP vous propose la vente de capuchons de toutes sortes. Ils répondront à vos besoins.

Spécialiste du bouchon en plastique, MOCAP est fabricant de bouchons de protection, MOCAP est fabricant, de bouchons en silicone. Le groupe vous propose l’achat et la vente de bouchons en plastique ainsi que toute une gamme de produits tels que la pastille haute température, le capuchon en vinyle et le ruban autosoudant.



Thick Extra Wide Flange Tapered Plug Caps - Information

MOCAP Thick Extra Wide Flange Tapered Plastic Plug Caps are inexpensive dual function closures which can be used as either a plug or a cap. These tapered polyethylene plug caps are made from tough but flexible polyethylene to form a secure fit, yet are easily removed.
These Plastic Plugs feature flanges which are thick and wider than any of our other plug-cap series. Over-sized flanges and the high-visibility color require removal before assembly operations.
Recommended to use as a cap for tube and hydraulic fittings, tube end caps, pipe caps or product protection. Or use as a plug for threaded holes, openings, fittings and ports.

  • Durable and Flexible - Use as a Cap or Plug
  • Protects Against Debris, Damage, Moisture and Corrosion
  • MOCAP stocks Thick Extra Wide Flange Tapered Plug Caps in many sizes for immediate shipment.


Functions as a Cap
MOCAP's XW Plastic Plug Caps have a tapered design which allow it to be used as a cap for multiple threaded and non-threaded applications.

Functions as a Plug
Use MOCAP XW Tapered Plug Caps to plug a wide range of openings, including threaded and non-threaded holes, pipe and tube end plugs, connector ports and fittings.

Masking Applications
MOCAP Plug Caps can also be used as inexpensive, single use disposable masking caps or masking plugs for painting, coating and spraying processes up to 175°F(79°C).


MOCAP stocks Thick Extra Wide Flange Tapered Plug Caps in many sizes for immediate shipment.

MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.







RoHS


Diagram
