Sealing Plugs for BSP Threads

SPB


BSP Sealing Plugs with Slotted Hex Head
Sealing Plugs for BSP Threads

SPB–Media

Sealing Plugs for BSP Threads Sealing Plug for BSP Threads BSP Sealing Plug Plastic BSP Sealing Plugs British Standard Pipe Sealing Plug BSP Sealing Plugs with Slotted Hex Head Plastic Bolt for BSP Threads
  • Material: PP (Polypropylene), Nylon
  • Stocked Material: PP (Red), NYLON (Yellow)
  • Designed with Five Complete Threads Plus an Integrated Sealing Lip for a Tight Fit
  • Also Available with a Factory Fit Neoprene O-Ring when a Secure Seal is Required

Size Chart BSP Sealing Plug

SPB Size Chart

Table View
List View
Part # Description To Fit BSP Flange OD
in
mm
 Stem Height
in
mm
 O-Ring Box/Mini/Micro
QTY		 Buy Online
More info
SPB0250 Sealing Plugs for BSP Threads - SEALING PLUG FOR BSP 1/4 THRDS G1/4
0.760
19.3
0.390
9.9
 5000 1000 100
SPB0250NO Polypropylene or Nylon BSP Sealing Plugs - SEALING PLUG FOR BSP 1/4 THRDS BASE KIT G1/4
0.760
19.3
0.390
9.9
 ✓ 5000 1000 100
SPB0375 Plastic BSP Sealing Plug Caps - SEALING PLUG FOR BSP 3/8 THRDS G3/8
0.870
22.1
0.430
10.9
 5000 1000 100
SPB0375NO Plastic Bolt for BSP Threads - SEALING PLUG FOR BSP 3/8 THRDS BASE KIT G3/8
0.870
22.1
0.430
10.9
 ✓ 5000 1000 100
SPB0500 BSP Sealing Plugs with Slotted Hex Head - SEALING PLUG FOR BSP 1/2 THRDS G1/2
1.070
27.2
0.510
12.9
 3000 600 60
SPB0500NO British Standard Pipe Sealing Plug - SEALING PLUG FOR BSP 1/2 THRDS BASE KIT G1/2
1.070
27.2
0.510
12.9
 ✓ 3000 600 60
SPB0750 Plastic BSP Sealing Plugs - SEALING PLUG FOR BSP 3/4 THRDS G3/4
1.270
32.3
0.510
12.9
 2000 400 40
SPB0750NO BSP Sealing Plug - SEALING PLUG FOR BSP 3/4 THRDS BASE KIT G3/4
1.270
32.3
0.510
12.9
 ✓ 2000 400 40
SPB1000 Sealing Plug for BSP Threads - SEALING PLUG FOR BSP 1 THRDS G1
1.570
39.9
0.550
14.0
 1000 200 20
SPB1000NO Sealing Plugs for BSP Threads - SEALING PLUG FOR BSP 1 THRDS BASE KIT G1
1.570
39.9
0.550
14.0
 ✓ 1000 200 20
SPB1250 Polypropylene or Nylon BSP Sealing Plugs - SEALING PLUG FOR BSP 1-1/4 THRDS G1-1/4
1.980
50.3
0.590
15.0
 1000 200 20
SPB1250NO Plastic BSP Sealing Plug Caps - SEALING PLUG FOR BSP 1-1/4 THRDS BASE KIT G1-1/4
1.980
50.3
0.590
15.0
 ✓ 1000 200 20
SPB1500 Plastic Bolt for BSP Threads - SEALING PLUG FOR BSP 1-1/2 THRDS G1-1/2
2.180
55.4
0.590
15.0
 250 50 5
SPB1500NO BSP Sealing Plugs with Slotted Hex Head - SEALING PLUG FOR BSP 1-1/2 THRDS BASE KIT G1-1/2
2.180
55.4
0.590
15.0
 ✓ 250 50 5
SPB2000 British Standard Pipe Sealing Plug - SEALING PLUG FOR BSP 2 THRDS G2
2.690
68.3
0.590
15.0
 200 40 4
SPB2000NO Plastic BSP Sealing Plugs - SEALING PLUG FOR BSP 2 THRDS BASE KIT G2
2.690
68.3
0.590
15.0
 ✓ 200 40 4
Part # Description To Fit BSP Flange OD
in
mm
 Stem Height
in
mm
 O-Ring Box/Mini/Micro
QTY		 Buy Online
More info
Legend:
- Add to Cart - View Price

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.
MOCAP vous propose la vente de capuchons de toutes sortes. Ils répondront à vos besoins.

Spécialiste du bouchon en plastique, MOCAP est fabricant de bouchons de protection, MOCAP est fabricant, de bouchons en silicone. Le groupe vous propose l’achat et la vente de bouchons en plastique ainsi que toute une gamme de produits tels que la pastille haute température, le capuchon en vinyle et le ruban autosoudant.



Sealing Plugs for BSP Threads - Information

MOCAP Sealing Plugs for BSP Threads are designed to protect British Standard Pipe Fittings from moisture, dust and damage during production, shipping and storage. Five complete threads plus a sealing lip provide a tight fit and secure seal. Can be applied and removed by hand, with a socket wrench, screwdriver or power tool.

Our SPB Series Plugs are:


  • Molded in Red Polypropylene(Standard applications)or
  • Yellow Nylon (offers high resistance against hydraulic fluids, solvents, acids and base alkalines)
  • Sized to fit BSP Threads from 1/4 thru 2.

These Sealing Plugs are also available with a factory-fit Neoprene Rubber O-Ring when a perfect seal is required.

MOCAP stocks Sealing Plugs for BSP Threads in both Red Polypropylene and Yellow Nylon materials in many sizes for immediate shipment.

MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.







RoHS
