Bolt Hole Flange Protectors

 800.633.6775


Bolt Hole Flange Protectors

MBH


Plastic Bolt Hole Flange Plugs
Bolt Hole Flange Protectors

MBH–Media

Bolt Hole Flange Protectors Studded Protector Cap for Bolt Hole Flanges Plastic Bolt Hole Flange Protection Plastic Raised Face Flange Protectors Plastic Full Face Flange Protectors Plastic Bolt Hole Flange Plugs Protectors for Bolt Hole Flanges Snap-on Bolt Hole Flange Caps
  • Material: LDPE (Low Density Polyethylene)
  • Stocked Material: LDPE (Black), LDPE (Blue)
  • Designed to Snap-In Easily Without Additional Fasteners

Size Chart Plastic Bolt Hole Flange Protection

MBH Size Chart

Table View
List View
Part # Description To Fit Nominal Pipe Size DIN Pipe Pressure Rating Nominal Pressure Color Box/Mini/Micro
QTY
Buy Online
More info
MBH150500 Bolt Hole Flange Protectors - 1/2" NOMINAL SIZE - FOR 125 & 150 LB 1/2” DN 15 #125, #150 20 800 160 16
MBH300500 Plastic Bolt Hole Flange Cover - 1/2" NOMINAL SIZE - FOR 300, 400 & 600 LB 1/2” DN 15 #300, #400, #600 50, 64, 100 800 160 16
MBH150750 Snap-on Bolt Hole Flange Caps - 3/4" NOMINAL SIZE - FOR 125 & 150 LB 3/4” DN 20 #125, #150 20 800 160 16
MBH300750 Protectors for Bolt Hole Flanges - 3/4" NOMINAL SIZE - FOR 300, 400 & 600 LB 3/4” DN 20 #300, #400, #600 50, 64, 100 500 100 10
MBH1501000 Plastic Bolt Hole Flange Plugs - 1" NOMINAL SIZE - FOR 125 & 150 LB 1 ” DN 25 #125, #150 20 600 120 12
MBH3001000 Plastic Full Face Flange Protectors - 1" NOMINAL SIZE - FOR 300, 400 & 600 LB 1 ” DN 25 #300, #400, #600 50, 64, 100 400 80 8
MBH1501250 Plastic Raised Face Flange Protectors - 1-1/4" NOMINAL SIZE - FOR 125 & 150 LB 1-1/4” DN 32 #125, #150 20 500 100 10
MBH3001250 Plastic Bolt Hole Flange Protection - 1-1/4" NOMINAL SIZE - FOR 300, 400 & 600 LB 1-1/4” DN 32 #300, #400, #600 50, 64, 100 300 60 6
MBH1501500 Studded Protector Cap for Bolt Hole Flanges - 1-1/2" NOMINAL SIZE - FOR 125 & 150 LB 1-1/2” DN 40 #125, #150 20 400 80 8
MBH3001500 Bolt Hole Flange Protectors - 1-1/2" NOMINAL SIZE - FOR 300, 400 & 600 LB 1-1/2” DN 40 #300, #400, #600 50, 64, 100 250 50 5
MBH1502000 Plastic Bolt Hole Flange Cover - 2" NOMINAL SIZE - FOR 125 & 150 LB 2 ” DN 50 #125, #150 20 200 40 4
MBH3002000 Snap-on Bolt Hole Flange Caps - 2" NOMINAL SIZE - FOR 300, 400 & 600 LB 2 ” DN 50 #300, #400, #600 50, 64, 100 150 30 3
MBH1502500 Protectors for Bolt Hole Flanges - 2-1/2" NOMINAL SIZE - FOR 125 & 150 LB 2-1/2” DN 65 #125, #150 20 150 30 3
MBH3002500 Plastic Bolt Hole Flange Plugs - 2-1/2" NOMINAL SIZE - FOR 300, 400 & 600 LB 2-1/2” DN 65 #300, #400, #600 50, 64, 100 100 20 2
MBH1503000 Plastic Full Face Flange Protectors - 3" NOMINAL SIZE - FOR 125 & 150 LB 3 ” DN 80 #125, #150 20 100 20 2
MBH3003000 Plastic Raised Face Flange Protectors - 3" NOMINAL SIZE - FOR 300, 400 & 600 LB 3 ” DN 80 #300, #400, #600 50, 64, 100 100 20 2
MBH1504000 Plastic Bolt Hole Flange Protection - 4" NOMINAL SIZE - FOR 125 & 150 LB 4 ” DN 100 #125, #150 20 100 20 2
MBH3004000 Studded Protector Cap for Bolt Hole Flanges - 4" NOMINAL SIZE - FOR 300 LB 4 ” DN 100 #300 50 80 16 1
MBH1505000 Bolt Hole Flange Protectors - 5" NOMINAL SIZE - FOR 125 & 150 LB 5 ” DN 125 #125, #150 20 100 20 2
MBH3005000 Plastic Bolt Hole Flange Cover - 5" NOMINAL SIZE - FOR 300 LB 5 ” DN 125 #300 50 100 20 2
MBH1506000 Snap-on Bolt Hole Flange Caps - 6" NOMINAL SIZE - FOR 125 & 150 LB 6 ” DN 150 #125, #150 20 90 18 1
MBH3006000 Protectors for Bolt Hole Flanges - 6" NOMINAL SIZE - FOR 300 LB 6 ” DN 150 #300 50 100 20 2
MBH1508000 Plastic Bolt Hole Flange Plugs - 8" NOMINAL SIZE - FOR 125 & 150 LB 8 ” DN 200 #125, #150 20 100 20 2
MBH3008000 Plastic Full Face Flange Protectors - 8" NOMINAL SIZE - FOR 300 LB 8 ” DN 200 #300 50 100 20 2
MBH15010000 Plastic Raised Face Flange Protectors - 10" NOMINAL SIZE - FOR 125 & 150 LB 10 ” DN 250 #125, #150 20 60 12 1
MBH30010000 Plastic Bolt Hole Flange Protection - 10" NOMINAL SIZE - FOR 300 LB 10 ” DN 250 #300 50 60 12 1
MBH15012000 Studded Protector Cap for Bolt Hole Flanges - 12" NOMINAL SIZE - FOR 125 & 150 LB 12 ” DN 300 #125, #150 20 40 8 1
MBH30012000 Bolt Hole Flange Protectors - 12" NOMINAL SIZE - FOR 300 LB 12 ” DN 300 #300 50 30 6 1
Part # Description To Fit Nominal Pipe Size DIN Pipe Pressure Rating Nominal Pressure Color Box/Mini/Micro
QTY
Buy Online
More info
Legend:
- Add to Cart - View Price

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.
MOCAP vous propose la vente de capuchons de toutes sortes. Ils répondront à vos besoins.

Spécialiste du bouchon en plastique, MOCAP est fabricant de bouchons de protection, MOCAP est fabricant, de bouchons en silicone. Le groupe vous propose l’achat et la vente de bouchons en plastique ainsi que toute une gamme de produits tels que la pastille haute température, le capuchon en vinyle et le ruban autosoudant.



Bolt Hole Flange Protectors - Information

MOCAP Bolt Hole Flange Protectors are the most commonly used flange protectors in the industry. Our MBH series products provide for easy installation and removal and are designed to protect flanges from damage and debris during transit, handling and storage.
Our MBH Series parts are molded in black and blue LDPE plastic to fit 1/2" thru 12" nominal sized pipe flanges.

MOCAP stocks Bolt Hole Flange Protectors in many sizes for immediate shipment.

MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.
