High Temperature Vinyl Insertion Plugs

MCP-T


High-Temp Vinyl Insertion Plugs
High Temperature Vinyl Insertion Plugs

MCP-T–Media

High Temp Vinyl Insertion Plugs Hi-Temp Plastic Plug High Temp Plastic Plug Hi-Temp Insertion Plugs High Temp Vinyl Insertion Plug High-Temp Vinyl Insertion Plugs Hi-Temp Plastic Plug High Temp Plastic Insertion Plug Plastic Insertion Plugs High Temperature Vinyl Insertion Plugs
  • Material: High-Temp Vinyl (Black)
  • Flexible Yet Durable - Won't Split, Tear or Shred
  • Wide Flange for Easy Removal

Size Chart High Temp Plastic Plug

MCP-T Size Chart

Table View
List View
Part # Description To Fit STD Thread To Fit METRIC Thread To Fit NPT Flange OD
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
MCP9252T High Temperature Vinyl Insertion Plugs - MCP-05 HT201-2 INSERTION PLUG 1/4 M6
0.400
10.2
 5280 1056 105
MCP9253T Plastic Insertion Plugs - MCP-1 HT INSERTION PLUG 5/16 M8
0.460
11.7
 5280 1056 105
MCP9254T High Temp Plastic Insertion Plug - MCP-2 HT INSERTION PLUG 3/8 M10 1/8
0.495
12.6
 5280 1056 105
MCP9255T Hi-Temp Plastic Plug - MCP-25 HT INSERTION PLUG 7/16 M12
0.550
14.0
 5040 1008 100
MCP9256T High-Temp Vinyl Insertion Plugs - MCP-3 HT INSERTION PLUG 1/2 M14 1/4
0.620
15.7
 5100 1020 102
MCP9257T High Temp Vinyl Insertion Plug - MCP-35 HT INSERTION PLUG 9/16 M16
0.683
17.3
 5200 1040 104
MCP9258T Hi-Temp Insertion Plugs - MCP-4 HT INSERTION PLUG 5/8 M18 3/8
0.807
20.5
 5120 1024 102
MCP9259T High Temp Plastic Plug - MCP-5 HT INSERTION PLUG 3/4 M20 1/2
0.961
24.4
 5320 1064 106
MCP9260T Hi-Temp Plastic Plug - MCP-55 HT INSERTION PLUG 7/8 M22, M24
1.058
26.9
 5200 1040 104
MCP9261T High Temperature Vinyl Insertion Plugs - MCP-6 HT INSERTION PLUG 1-1/16 M26, M28 3/4
1.245
31.6
 2552 510 51
MCP9262T Plastic Insertion Plugs - MCP-7 HT INSERTION PLUG 1-1/8, 1-3/16, 1-1/4 M32, M34 1
1.495
38.0
 2516 503 50
Part # Description To Fit STD Thread To Fit METRIC Thread To Fit NPT Flange OD
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
Legend:
- Add to Cart - View Price

NOTE: Due to the inherent variability of the dip-molding process, the "Flange OD" may vary by +/-1.6mm (1/16") from the figures shown above.

Wall thickness is measured approx. ¼” (6.35mm) from open end. Wall thickness increases slightly towards the closed end of the part

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.
MOCAP vous propose la vente de capuchons de toutes sortes. Ils répondront à vos besoins.

Spécialiste du bouchon en plastique, MOCAP est fabricant de bouchons de protection, MOCAP est fabricant, de bouchons en silicone. Le groupe vous propose l’achat et la vente de bouchons en plastique ainsi que toute une gamme de produits tels que la pastille haute température, le capuchon en vinyle et le ruban autosoudant.



High Temperature Vinyl Insertion Plugs - Information

MOCAP High Temperature Vinyl Plastic Masking Plugs are a low cost quality answer to your masking needs. Flexible material allows these plastic plugs to seal threaded and non-threaded openings. Special high temperature resistant vinyl material withstands up to 475°F(246°C).
High temperature vinyl Insertion Masking Plugs are available in sizes to fit 1/4 through 1-1/4 standard threaded openings and M6 through M43 metric threaded holes.

High temperature resistant tapered plugs and Nut Plugs also available.








RoHS


Diagram
