Plugs for Oval Tubes
OV
Plastic Stoppers For Steel Tubing
View Larger Image
OV–Media
- Material: LDPE (Low Density Polyethylene)
- Stocked Material: LDPE (Black)
- Multiple Ribs for a Secure Fit
- Heavy End Walls for Durability and Abrasion Resistance
Available in the following varieties:
Plugs for Oval Tubes with Flat Top
Plugs for Oval Tubes with Domed Top
Plugs for Oval Tubes with Curved Top
Size Chart Floor protector for metal chair legs
OV Size Chart
| Part # | Description | Imperial or Metric |
Small External Tube Size in mm |
Large External Tube Size in mm |
Tube Wall | Curved Plug Length in mm |
Length in mm |
Box/Mini/Micro QTY |
 Flat |
 Dome |
 Curved |
Buy Online More info |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| OV2010MI | Plugs for Oval Tubes - OVAL TUBING PLUG FOR 10X20MM OD LDPE | Metric | 0.394 10.0 |
0.787 20.0 |
.75 - 2mm | - - |
0.453 11.5 |
2000 400 40 |  |  | ||
| OV2510MI | Plastic Oval Tube Plugs (Metric or Standard) - OVAL TUBING PLUG FOR 10X25MM OD LDPE | Metric | 0.394 10.0 |
0.984 25.0 |
.75 - 2mm | - - |
0.453 11.5 |
2000 400 40 | | | ||
| OV3010MI | Oval Tubing Blanking Caps for Legs - OVAL TUBING PLUG FOR 10X30MM OD LDPE | Metric | 0.394 10.0 |
1.181 30.0 |
.75 - 2mm | - - |
0.453 11.5 |
1000 200 20 | | | ||
| OV3015MF | End Plugs for Oval Tubing - OVAL TUBING PLUG FOR 15X30MM OD LDPE | Metric | 0.591 15.0 |
1.181 30.0 |
2 - 3mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV3015MA | Plastic Stoppers For Steel Tubing - OVAL TUBING PLUG FOR 15X30MM OD LDPE | Metric | 0.591 15.0 |
1.181 30.0 |
1 - 2mm | 0.984 25.0 |
0.453 11.5 |
1000 200 20 | | | 0-21° |
|
| OV3515MF | Oval Plastic Furniture Glides - OVAL TUBING PLUG FOR 15X35MM OD LDPE | Metric | 0.591 15.0 |
1.378 35.0 |
2 - 3mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV3515MI | Chair Leg Plastic Glide - OVAL TUBING PLUG FOR 15X35MM OD LDPE | Metric | 0.591 15.0 |
1.378 35.0 |
.75 - 2mm | - - |
0.453 11.5 |
1000 200 20 | | | ||
| OV5015MA | Floor protector for metal chair legs - OVAL TUBING PLUG FOR 15X50MM OD LDPE | Metric | 0.591 15.0 |
1.969 50.0 |
1 - 2mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV5015MF | Patio Furniture Repair Insert - OVAL TUBING PLUG FOR 15X50MM OD LDPE | Metric | 0.591 15.0 |
1.969 50.0 |
2 - 3mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV.625X1.25C | Plugs for Oval Tubes - OVAL TUBING PLUG FOR 0.625"X1.250" OD LDPE | Imperial | 0.625 15.9 |
1.250 31.8 |
.035-.083" (20-14ga) | - - |
0.453 11.5 |
2000 200 20 | | |||
| OV4518MA | Plastic Oval Tube Plugs (Metric or Standard) - OVAL TUBING PLUG FOR 18X45MM OD LDPE | Metric | 0.709 18.0 |
1.772 45.0 |
1 - 2mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV4518MF | Oval Tubing Blanking Caps for Legs - OVAL TUBING PLUG FOR 18X45MM OD LDPE | Metric | 0.709 18.0 |
1.772 45.0 |
2 - 3mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV.75X1.5I | End Plugs for Oval Tubing - OVAL TUBING PLUG FOR 0.750"X1.500" OD LDPE | Imperial | 0.750 19.1 |
1.500 38.1 |
.025-.065" (23-16ga) | - - |
0.453 11.5 |
2000 200 20 | | |||
| OV3520MA | Plastic Stoppers For Steel Tubing - OVAL TUBING PLUG FOR 20X35MM OD LDPE | Metric | 0.787 20.0 |
1.378 35.0 |
1 - 2mm | - - |
0.453 11.5 |
1000 200 20 | | | ||
| OV3520MF | Oval Plastic Furniture Glides - OVAL TUBING PLUG FOR 20X35MM OD LDPE | Metric | 0.787 20.0 |
1.378 35.0 |
2 - 3mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV3820MF | Chair Leg Plastic Glide - OVAL TUBING PLUG FOR 20X38MM OD LDPE | Metric | 0.787 20.0 |
1.496 38.0 |
2 - 3mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV3820MA | Floor protector for metal chair legs - OVAL TUBING PLUG FOR 20X38MM OD LDPE | Metric | 0.787 20.0 |
1.496 38.0 |
1 - 2mm | 0.984 25.0 |
0.453 11.5 |
1000 200 20 | | | 0-21° |
|
| OV4020MF | Patio Furniture Repair Insert - OVAL TUBING PLUG FOR 20X40MM OD LDPE | Metric | 0.787 20.0 |
1.575 40.0 |
2 - 3mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV4020MI | Plugs for Oval Tubes - OVAL TUBING PLUG FOR 20X40MM OD LDPE | Metric | 0.787 20.0 |
1.575 40.0 |
.75 - 2mm | 0.984 25.0 |
0.453 11.5 |
1000 200 20 | | | 0-21° |
|
| OV4520MA | Plastic Oval Tube Plugs (Metric or Standard) - OVAL TUBING PLUG FOR 20X45MM OD LDPE | Metric | 0.787 20.0 |
1.772 45.0 |
1 - 2mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV4520MF | Oval Tubing Blanking Caps for Legs - OVAL TUBING PLUG FOR 20X45MM OD LDPE | Metric | 0.787 20.0 |
1.772 45.0 |
2 - 3mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV4820MF | End Plugs for Oval Tubing - OVAL TUBING PLUG FOR 20X48MM OD LDPE | Metric | 0.787 20.0 |
1.890 48.0 |
2 - 3mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV4820MA | Plastic Stoppers For Steel Tubing - OVAL TUBING PLUG FOR 20X48MM OD LDPE | Metric | 0.787 20.0 |
1.890 48.0 |
1 - 2mm | 0.984 25.0 |
0.453 11.5 |
1000 200 20 | | | 0-21° |
|
| OV5020MA | Oval Plastic Furniture Glides - OVAL TUBING PLUG FOR 20X50MM OD LDPE | Metric | 0.787 20.0 |
1.969 50.0 |
1 - 2mm | - - |
0.453 11.5 |
1000 200 20 | | | ||
| OV5020MF | Chair Leg Plastic Glide - OVAL TUBING PLUG FOR 20X50MM OD LDPE | Metric | 0.787 20.0 |
1.969 50.0 |
2 - 3mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV6020MF | Floor protector for metal chair legs - OVAL TUBING PLUG FOR 20X60MM OD LDPE | Metric | 0.787 20.0 |
2.362 60.0 |
2 - 3mm | - - |
0.453 11.5 |
500 100 10 | | |||
| OV6020MI | Patio Furniture Repair Insert - OVAL TUBING PLUG FOR 20X60MM OD LDPE | Metric | 0.787 20.0 |
2.362 60.0 |
.75 - 2mm | - - |
0.453 11.5 |
500 100 10 | | | ||
| OV4025MA | Plugs for Oval Tubes - OVAL TUBING PLUG FOR 25X40MM OD LDPE | Metric | 0.984 25.0 |
1.575 40.0 |
1 - 2mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV4025MF | Plastic Oval Tube Plugs (Metric or Standard) - OVAL TUBING PLUG FOR 25X40MM OD LDPE | Metric | 0.984 25.0 |
1.575 40.0 |
2 - 3mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV5025MA | Oval Tubing Blanking Caps for Legs - OVAL TUBING PLUG FOR 25X50MM OD LDPE | Metric | 0.984 25.0 |
1.969 50.0 |
1 - 2mm | - - |
0.453 11.5 |
1000 200 20 | | | ||
| OV5025MF | End Plugs for Oval Tubing - OVAL TUBING PLUG FOR 25X50MM OD LDPE | Metric | 0.984 25.0 |
1.969 50.0 |
2 - 3mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV6025MA | Plastic Stoppers For Steel Tubing - OVAL TUBING PLUG FOR 25X60MM OD LDPE | Metric | 0.984 25.0 |
2.362 60.0 |
1 - 2mm | - - |
0.571 14.5 |
500 100 10 | | |||
| OV6025MF | Oval Plastic Furniture Glides - OVAL TUBING PLUG FOR 25X60MM OD LDPE | Metric | 0.984 25.0 |
2.362 60.0 |
2 - 3mm | - - |
0.571 14.5 |
500 100 10 | | |||
| OV8025MA | Chair Leg Plastic Glide - OVAL TUBING PLUG FOR 25X80MM OD LDPE | Metric | 0.984 25.0 |
3.150 80.0 |
1 - 2mm | - - |
0.571 14.5 |
400 80 8 | | | ||
| OV8025MF | Floor protector for metal chair legs - OVAL TUBING PLUG FOR 25X80MM OD LDPE | Metric | 0.984 25.0 |
3.150 80.0 |
2 - 3mm | - - |
0.571 14.5 |
400 80 8 | | |||
| OV5030MA | Patio Furniture Repair Insert - OVAL TUBING PLUG FOR 30X50MM OD LDPE | Metric | 1.181 30.0 |
1.969 50.0 |
1 - 2mm | - - |
0.453 11.5 |
1000 200 20 | | | ||
| OV5030MF | Plugs for Oval Tubes - OVAL TUBING PLUG FOR 30X50MM OD LDPE | Metric | 1.181 30.0 |
1.969 50.0 |
2 - 3mm | - - |
0.453 11.5 |
1000 200 20 | | |||
| OV6030MA | Plastic Oval Tube Plugs (Metric or Standard) - OVAL TUBING PLUG FOR 30X60MM OD LDPE | Metric | 1.181 30.0 |
2.362 60.0 |
1 - 2mm | - - |
0.571 14.5 |
500 100 10 | | | ||
| OV7040MA | Oval Tubing Blanking Caps for Legs - OVAL TUBING PLUG FOR 40X70MM OD LDPE | Metric | 1.575 40.0 |
2.756 70.0 |
1 - 2mm | - - |
0.571 14.5 |
500 100 10 | | | ||
| OV7040MF | End Plugs for Oval Tubing - OVAL TUBING PLUG FOR 40X70MM OD LDPE | Metric | 1.575 40.0 |
2.756 70.0 |
2 - 3mm | - - |
0.571 14.5 |
500 100 10 | | |||
| OV8040MA | Plastic Stoppers For Steel Tubing - OVAL TUBING PLUG FOR 40X80MM OD LDPE | Metric | 1.575 40.0 |
3.150 80.0 |
1 - 2mm | - - |
0.571 14.5 |
400 80 8 | | |||
| OV8040MF | Oval Plastic Furniture Glides - OVAL TUBING PLUG FOR 40X80MM OD LDPE | Metric | 1.575 40.0 |
3.150 80.0 |
2 - 3mm | - - |
0.571 14.5 |
400 80 8 | | |||
| Part # | Description | Imperial or Metric |
Small External Tube Size in mm |
Large External Tube Size in mm |
Tube Wall | Curved Plug Length in mm |
Length in mm |
Box/Mini/Micro QTY |
Flat |
Dome |
Curved |
Buy Online More info |
Legend:
- Add to Cart
- View Price
Plugs with an curved top are longer than the other varieties. The length is indicated in the "Curved Plug Length" column.
Micropacks are only available for purchase through our online store.
Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.
MOCAP vous propose la vente de capuchons de toutes sortes. Ils répondront à vos besoins.
Spécialiste du bouchon en plastique, MOCAP est fabricant de bouchons de protection, MOCAP est fabricant, de bouchons en silicone. Le groupe vous propose l’achat et la vente de bouchons en plastique ainsi que toute une gamme de produits tels que la pastille haute température, le capuchon en vinyle et le ruban autosoudant.
Spécialiste du bouchon en plastique, MOCAP est fabricant de bouchons de protection, MOCAP est fabricant, de bouchons en silicone. Le groupe vous propose l’achat et la vente de bouchons en plastique ainsi que toute une gamme de produits tels que la pastille haute température, le capuchon en vinyle et le ruban autosoudant.
Plugs for Oval Tubes - Information
MOCAP OV Series heavy wall polyethylene plugs for Oval tubing are designed to fit multiple tube gauges and provide a secure fit. Poly tube plugs are ideal for office and patio furniture, tubular racks, appliances, exercise equipment, or anywhere a finished look is needed. Tube plugs include multiple horizontal ribs designed with built-in flexibility for easy install and secure fit. OV Tubing Plugs are available in sizes to fit 10mm x 20mm to 40mm x 80mm metric Oval tubes and 5/8" x 1-1/4" to 3/4" x 1-1/2" diameter standard Oval tubes.
- Multiple Ribs for Secure Fit
- Tube Plugs Fit Multiple Gauges
- Stocked in Black LDPE, but can also be produced in a wide range of colors.
MOCAP stocks Plugs for Oval Tubes in many sizes for immediate shipment.
MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.
Sizes Available to Fit Standard and Metric Tubes.
