Sheet Metal Hole Plugs Recessed Standard

SMRS


LDPE Plastic Caps for Metal Panel Access Holes
Sheet Metal Hole Plugs Recessed Standard

SMRS–Media

Recessed Sheet Metal Plugs for Standard Holes Recessed Sheet Metal Plug for Standard Holes Plastic Plugs For Sheet Metal Holes Plastic Sheet Metal Panel Plugs Protective Sheet Metal Hole Plugs LDPE Plastic Caps for Metal Panel Access Holes Sheet Metal Hole Cover - Recessed Solid Grommet Plastic Plugs For Sheet Metal Holes Plastic Snap-in LDPE Panel Plugs
  • Material: LDPE (Low Density Polyethylene)
  • Stocked Material: LDPE (Black)
  • Snap-in Design for an Attractive and Secure Fit
  • Used on Auto Bodies, Tanks, HVAC Units, etc.

Size Chart Plastic Plugs For Sheet Metal Holes

SMRS Size Chart

Table View
List View
Part # Description To Fit Hole Size Metal Thickness Small O.D.
in
mm
 Flange OD
in
mm
 Length
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
SMR1/2 Sheet Metal Hole Plugs Recessed Standard - SHEET MTL PLUG RCSSD FOR 0.500" (1/2") OPENING .50"- .53" (12.70 - 13.46mm) .02"- .07" (.51 - 1.78mm)
0.550
14.0
0.850
21.6
0.290
7.4
 5000 1000 100
SMR3/4 Plastic Snap-in LDPE Panel Plugs - SHEET MTL PLUG RCSSD FOR 0.750" (3/4") OPENING .74"- .77" (18.80 - 19.56mm) .02"- .14" (.51 - 3.56mm)
0.810
20.6
1.160
29.5
0.320
8.1
 5000 1000 100
SMR13/16 Plastic Plugs For Sheet Metal Holes - SHEET MTL PLUG RCSSD FOR 0.8125" (13/16") OPENING .79"- .83" (20.07 - 21.08mm) .02"- .07" (.51 - 1.78mm)
0.850
21.6
1.150
29.2
0.290
7.4
 5000 1000 100
SMR7/8 Sheet Metal Hole Cover - Recessed Solid Grommet - SHEET MTL PLUG RCSSD FOR 0.875" (7/8") OPENING .87"- .91" (22.10 - 23.11mm) .02"- .10" (.51 - 2.54mm)
0.930
23.6
1.230
31.2
0.350
8.9
 5000 1000 100
SMR1 LDPE Plastic Caps for Metal Panel Access Holes - SHEET MTL PLUG RCSSD FOR 1.000" (1") OPENING .99"- 1.03" (25.15 - 26.16mm) .02"- .10" (.51 - 2.54mm)
1.050
26.7
1.350
34.3
0.350
8.9
 6000 1200 120
SMR1-1/16 Protective Sheet Metal Hole Plugs - SHEET MTL PLUG RCSSD FOR 1.0625" (1-1/16") OPENING 1.04"- 1.08" (26.42 - 27.43mm) .02"- .10" (.51 - 2.54mm)
1.100
27.9
1.400
35.6
0.350
8.9
 5500 1100 110
SMR1-1/8 Plastic Sheet Metal Panel Plugs - SHEET MTL PLUG RCSSD FOR 1.125" (1-1/8") OPENING 1.11"- 1.16" (28.19 - 29.46mm) .02"- .18" (.51 - 4.57mm)
1.180
30.0
1.530
38.9
0.430
10.9
 4000 800 80
SMR1-1/4 Plastic Plugs For Sheet Metal Holes - SHEET MTL PLUG RCSSD FOR 1.250" (1-1/4") OPENING 1.24"- 1.28" (31.50 - 32.51mm) .02"- .10" (.51 - 2.54mm)
1.300
33.0
1.600
40.6
0.350
8.9
 4000 800 80
SMR1-3/8 Recessed Sheet Metal Plug for Standard Holes - SHEET MTL PLUG RCSSD FOR 1.375" (1-3/8") OPENING 1.36"- 1.41" (34.54 - 35.81mm) .02"- .10" (.51 - 2.54mm)
1.430
36.3
1.730
43.9
0.350
8.9
 3800 760 76
SMR1-1/2-7 Sheet Metal Hole Plugs Recessed Standard - SHEET MTL PLUG RCSSD FOR 1.500" (1-1/2") OPENING 1.48"- 1.52" (37.59 - 38.61mm) .13"- .22" (3.3 - 5.59mm)
1.540
39.1
1.830
46.5
0.500
12.7
 2000 400 40
SMR1-1/2 Plastic Snap-in LDPE Panel Plugs - SHEET MTL PLUG RCSSD FOR 1.500" (1-1/2") OPENING 1.48"- 1.53" (37.59 - 38.86mm) .02"- .10" (.51 -2.54mm)
1.550
39.4
1.850
47.0
0.350
8.9
 3000 600 60
SMR1-5/8 Plastic Plugs For Sheet Metal Holes - SHEET MTL PLUG RCSSD FOR 1.625" (1-5/8") OPENING 1.59"- 1.65" (40.39 - 41.91mm) .03"- .10" (.76 - 2.54mm)
1.680
42.7
2.000
50.8
0.360
9.1
 1500 300 30
SMR1-3/4 Sheet Metal Hole Cover - Recessed Solid Grommet - SHEET MTL PLUG RCSSD FOR 1.750" (1-3/4") OPENING 1.72"- 1.77" (43.69 - 44.96mm) .02"- .10" (.51 - 2.54mm)
1.800
45.7
2.100
53.3
0.350
8.9
 2500 500 50
SMR1-3/4-5 LDPE Plastic Caps for Metal Panel Access Holes - SHEET MTL PLUG RCSSD FOR 1.750" (1-3/4") OPENING 1.70"- 1.78" (43.18 - 45.21mm) .02"- .16" (.51 - 4.06mm)
1.800
45.7
2.250
57.2
0.430
10.9
 2000 400 40
SMR1-13/16 Protective Sheet Metal Hole Plugs - SHEET MTL PLUG RCSSD FOR 1.8125" (1-13/16") OPENING 1.77"- 1.82" (44.96 - 46.23mm) .02"- .10" (.51 - 2.54mm)
1.850
47.0
2.160
54.9
0.350
8.9
 2500 500 50
SMR1-7/8 Plastic Sheet Metal Panel Plugs - SHEET MTL PLUG RCSSD FOR 1.875" (1-7/8") OPENING 1.85"- 1.90" (46.99 - 48.26mm) .02"- .10" (.51 - 2.54mm)
1.930
49.0
2.240
56.9
0.350
8.9
 2000 400 40
SMR2 Plastic Plugs For Sheet Metal Holes - SHEET MTL PLUG RCSSD FOR 2.000" (2") OPENING 1.97"- 2.02" (50.04 - 51.31mm) .02"- .10" (.51 - 2.54mm)
2.050
52.1
2.350
59.7
0.360
9.1
 1000 200 20
SMR2-1/2 Recessed Sheet Metal Plug for Standard Holes - SHEET MTL PLUG RCSSD FOR 2.500" (2-1/2") OPENING 2.45"- 2.51" (62.23 - 63.75mm) .02"- .10" (.51 - 2.54mm)
2.540
64.5
2.850
72.4
0.350
8.9
 1000 200 20
SMR2-1/2-5 Sheet Metal Hole Plugs Recessed Standard - SHEET MTL PLUG RCSSD FOR 2.500" (2-1/2") OPENING 2.44"- 2.53" (61.98 - 64.26mm) .02"- .14" (.51 - 3.56mm)
2.550
64.8
3.000
76.2
0.430
10.9
 1000 200 20
Part # Description To Fit Hole Size Metal Thickness Small O.D.
in
mm
 Flange OD
in
mm
 Length
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
Legend:
- Add to Cart - View Price

Micropacks are only available for purchase through our online store.

MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.



Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.
MOCAP vous propose la vente de capuchons de toutes sortes. Ils répondront à vos besoins.

Spécialiste du bouchon en plastique, MOCAP est fabricant de bouchons de protection, MOCAP est fabricant, de bouchons en silicone. Le groupe vous propose l’achat et la vente de bouchons en plastique ainsi que toute une gamme de produits tels que la pastille haute température, le capuchon en vinyle et le ruban autosoudant.



Sheet Metal Hole Plugs Recessed Standard - Information

MOCAP LDPE Sheet Metal Hole Plugs are recessed head designed for standard size holes. Snap-in sheet metal hole plug provides an attractive finish and a secure fit. MOCAP polyethylene plastic sheet metal hole plugs are used to cap plug holes on appliances, automobiles, tanks or anywhere a finished look is needed. SMRS Series sheet metal plugs are available in sizes to fit 1/2" to 2-1/2" diameter holes.

  • Provides a Finished Look
  • Snap In Design for a Secure Fit
  • Designed for Sheet Metal and Thin Gauge Materials


Also Available:
Flush Head sheet metal hole plugs to fit 8mm to 22mm holes.
Flush Head sheet metal hole plugs to fit 3/8" to 4" holes.
MOCAP stocks Sheet Metal Hole Plugs Recessed Standard in many sizes for immediate shipment.






RoHS


Diagram
