Push-in Plugs for SAE and NPT Threads

PIP


Polyethylene Push-in-Plugs
Push-in Plugs for SAE and NPT Threads

PIP – Media

Push-in Plugs for SAE and NPT Threads NPT and SAE Push-in Plug Plastic NTP Protection Cap Plastic SAE Protection Cap Push-in Plug for NPT or SAE Threads Polyethylene Push-in-Plugs Plastic Push-in-Plugs for SAE and NPT Threads Plastic Push-in Cork Caps - SAE and NPT Threads Push-in Plugs for NPT and SAE Threads Push-in Plugs for SAE and NPT Threads
  • Material: LDPE (Low Density Polyethylene) (Red)
  • Designed to Simply Snap into Place to Protect Threads

Size Chart Plastic NTP Protection Cap

PIP Size Chart

Part # Description To Fit NPT To Fit SAE Diameter
in
mm
 Length
in
mm
 Flange OD
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
PIP0250RD1 Push-in Plugs for SAE and NPT Threads - PUSH IN PLUG FOR 1/4 SAE THRDS, LDPE RED 1/4"
0.206
5.2
0.220
5.6
0.452
11.5
 5000 1000 100
PIP0313RD1 Push-in Plugs for NPT and SAE Threads - PUSH IN PLUG FOR 5/16 SAE THRDS, LDPE RED 5/16"
0.262
6.7
0.235
6.0
0.527
13.4
 5000 1000 100
PIPL0375RD1 Plastic Push-in Cork Caps - SAE and NPT Threads - PUSH IN PLUG LONG FOR 3/8 SAE OR 1/8 NPT THRDS, LDPE RED 1/8" 3/8"
0.310
7.9
0.340
8.6
0.588
14.9
 5000 1000 100
PIP0375RD1 Plastic Push-in-Plugs for SAE and NPT Threads - PUSH IN PLUG FOR 3/8 SAE OR 1/8 NPT THREADS LDPE RED 1/8" 3/8"
0.324
8.2
0.235
6.0
0.588
14.9
 5000 1000 100
PIP0438RD1 Polyethylene Push-in-Plugs - PUSH IN PLUG FOR 7/16 SAE THRDS, LDPE RED 7/16"
0.380
9.7
0.270
6.9
0.656
16.7
 5000 1000 100
PIP0500RD1 Push-in Plug for NPT or SAE Threads - PUSH IN PLUG FOR 1/2 SAE OR 1/4 NPT THRDS, LDPE RED 1/4" 1/2"
0.437
11.1
0.270
6.9
0.724
18.4
 5000 1000 100
PIPL0563RD1 Plastic SAE Protection Cap - PUSH IN PLUG LONG FOR 9/16 SAE THRDS, LDPE RED 9/16"
0.480
12.2
0.360
9.1
0.835
21.2
 5000 1000 100
PIP0563RD1 Plastic NTP Protection Cap - PUSH IN PLUG FOR 9/16 SAE THRDS, LDPE RED 9/16"
0.495
12.6
0.290
7.4
0.810
20.6
 5000 1000 100
PIP0625RD1 NPT and SAE Push-in Plug - PUSH IN PLUG FOR 5/8 SAE OR 3/8 NPT THRDS, LDPE RED 3/8" 5/8"
0.558
14.2
0.290
7.4
0.971
24.7
 5000 1000 100
PIP0688RD1 Push-in Plugs for SAE and NPT Threads - PUSH IN PLUG FOR 11/16 SAE THRDS, LDPE RED 11/16"
0.610
15.5
0.290
7.4
1.008
25.6
 5000 1000 100
PIP0750RD1 Push-in Plugs for NPT and SAE Threads - PUSH IN PLUG FOR 3/4 SAE THRDS, LDPE RED 3/4"
0.676
17.2
0.290
7.4
1.045
26.5
 5000 1000 100
PIP0813RD1 Plastic Push-in Cork Caps - SAE and NPT Threads - PUSH IN PLUG FOR 13/16 SAE OR 1/2 NPT THRDS, LDPE RED 1/2" 13/16"
0.732
18.6
0.290
7.4
1.094
27.8
 5000 1000 100
PIP0875RD1 Plastic Push-in-Plugs for SAE and NPT Threads - PUSH IN PLUG FOR 7/8 SAE THRDS, LDPE RED 7/8"
0.798
20.3
0.295
7.5
1.172
29.8
 4500 900 90
PIP1000RD1 Polyethylene Push-in-Plugs - PUSH IN PLUG FOR 1 SAE OR 3/4 NPT THRDS, LDPE RED 3/4" 1"
0.922
23.4
0.290
7.4
1.305
33.1
 3500 700 70
PIP1062RD1 Push-in Plug for NPT or SAE Threads - PUSH IN PLUG FOR 1-1/16 SAE THRDS, LDPE RED 1-1/16"
0.972
24.7
0.290
7.4
1.417
36.0
 3000 600 60
PIP1188RD1 Plastic SAE Protection Cap - PUSH IN PLUG FOR 1-3/16 SAE THRDS, LDPE RED 1-3/16"
1.090
27.7
0.340
8.6
1.518
38.6
 2000 400 40
PIP1250RD1 Plastic NTP Protection Cap - PUSH IN PLUG FOR 1-1/4 SAE THRDS, LDPE RED 1-1/4"
1.160
29.5
0.340
8.6
1.571
39.9
 2000 400 40
PIP1313RD1 NPT and SAE Push-in Plug - PUSH IN PLUG FOR 1-5/16 SAE OR 1 NPT THRDS, LDPE RED 1" 1-5/16"
1.215
30.9
0.340
8.6
1.640
41.7
 2000 400 40
PIP1438RD1 Push-in Plugs for SAE and NPT Threads - PUSH IN PLUG FOR 1-7/16 SAE THRDS, LDPE RED 1-7/16"
1.360
34.5
0.460
11.7
1.803
45.8
 1200 240 24
PIP1500RD1 Push-in Plugs for NPT and SAE Threads - PUSH IN PLUG FOR 1-1/2 SAE THRDS, LDPE RED 1-1/2"
1.405
35.7
0.460
11.7
1.854
47.1
 1100 220 22
PIP1625RD1 Plastic Push-in Cork Caps - SAE and NPT Threads - PUSH IN PLUG FOR 1-5/8 SAE THRDS, LDPE RED 1-5/8"
1.525
38.7
0.460
11.7
1.982
50.3
 1000 200 20
PIP1750RD1 Plastic Push-in-Plugs for SAE and NPT Threads - PUSH IN PLUG FOR 1-3/4 SAE THRDS, LDPE RED 1-3/4"
1.650
41.9
0.460
11.7
2.117
53.8
 800 160 16
PIP1875RD1 Polyethylene Push-in-Plugs - PUSH IN PLUG FOR 1-7/8 SAE THRDS, LDPE RED 1-7/8"
1.775
45.1
0.460
11.7
2.216
56.3
 800 160 16
Part # Description To Fit NPT To Fit SAE Diameter
in
mm
 Length
in
mm
 Flange OD
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
Legend:
- Add to Cart - View Price
​
Micropacks are only available for purchase through our online store.
​

Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.
MOCAP vous propose la vente de capuchons de toutes sortes. Ils répondront à vos besoins.

Spécialiste du bouchon en plastique, MOCAP est fabricant de bouchons de protection, MOCAP est fabricant, de bouchons en silicone. Le groupe vous propose l’achat et la vente de bouchons en plastique ainsi que toute une gamme de produits tels que la pastille haute température, le capuchon en vinyle et le ruban autosoudant.



Push-in Plugs for SAE and NPT Threads - Information

MOCAP Push-In Plugs For SAE and NPT Threads are designed for easy push-in applications in both SAE and NPT threaded openings. While providing an attractive finishing look, the plugs will protect threads and fittings without the need to screw them in. Simply snap them into place.
Protects from moisture, dust and damage during production, shipping and storage.

Our PIP Series Plugs are molded in Red polyethylene plastic and sized to fit SAE Threads from 1/4 thru 1-7/8 or NPT Threads from 1/8 thru 1.

MOCAP stocks Push-in Plugs for SAE and NPT Threads in many sizes for immediate shipment.

MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.
