Threaded Plastic Plugs for Straight Thread O-Ring Ports

OPP


Plugs for SAE O-Ring Ports and MIL-MS-33649 Bosses
Threaded Plastic Plugs for Straight Thread O-Ring Ports

OPP–Media

O-Ring Port Plug SAE Straight Thread O-Ring Plugs Threaded Hydraulic Caps and Plugs Plastic MS33649 Fitting Fittings for Straight Thread O-Ring Ports Plugs for SAE O-Ring Ports and MIL-MS-33649 Bosses Straight Thread O-Ring Port Plastic Plug Caps (MS33649) Plastic Bolt for Straight Thread O-Ring Ports Threaded Plugs for Straight Thread O-Ring Ports
  • Material: PP (Polypropylene)
  • Stocked Material: PP (Red)
  • Designed to Provide a Positive Seal on SAE Straight-Thread O-Ring Type Ports and Mil-MS-33649 Bosses
  • Features Molded-In O-Ring Style Bead on the Outside of Head to Seal the Port Face from Oil Leakage

Size Chart Threaded Hydraulic Caps and Plugs

OPP Size Chart

Table View
List View
Part # Description To Fit STD Thread Length
in
mm
Flange OD
in
mm
Flange Thickness
in
mm
Box/Mini/Micro
QTY
Buy Online
More info
OPP0438 Threaded Plastic Plugs for Straight Thread O-Ring Ports - PLUG FOR 7/16-20 STR THRD O-RING PORT 7/16 - 20
0.320
8.1
0.650
16.5
0.380
9.6
5000 1000 100
OPP0500 Threaded Plugs for Straight Thread O-Ring Ports - PLUG FOR 1/2-20 STR THRD O-RING PORT 1/2 - 20
0.320
8.1
0.720
18.3
0.380
9.6
5000 1000 100
OPP0562 Plastic Bolt for Straight Thread O-Ring Ports - PLUG FOR 9/16-18 STR THRD O-RING PORT 9/16 - 18
0.360
9.1
0.780
19.8
0.380
9.6
5000 1000 100
OPP0750 Straight Thread O-Ring Port Plastic Plug Caps (MS33649) - PLUG FOR 3/4-16 STR THRD O-RING PORT 3/4 - 16
0.400
10.2
0.980
24.9
0.380
9.6
5000 1000 100
OPP0875 Plugs for SAE O-Ring Ports and MIL-MS-33649 Bosses - PLUG FOR 7/8-14 STR THRD O-RING PORT 7/8 - 14
0.450
11.4
1.110
28.2
0.380
9.6
2500 500 50
OPP1062 Fittings for Straight Thread O-Ring Ports - PLUG FOR 1-1/16-12 STR THRD O-RING PORT 1-1/16 - 12
0.620
15.7
1.310
33.3
0.380
9.6
2500 500 50
OPP1312 Plastic MS33649 Fitting - PLUG FOR 1-5/16-12 STR THRD O-RING PORT 1-5/16 - 12
0.620
15.7
1.560
39.6
0.380
9.6
1000 200 20
OPP1625 Threaded Hydraulic Caps and Plugs - PLUG FOR 1-5/8-12 STR THRD O-RING PORT 1-5/8 - 12
0.620
15.7
1.880
47.8
0.380
9.6
1000 200 20
Part # Description To Fit STD Thread Length
in
mm
Flange OD
in
mm
Flange Thickness
in
mm
Box/Mini/Micro
QTY
Buy Online
More info
Legend:
- Add to Cart - View Price

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.
MOCAP vous propose la vente de capuchons de toutes sortes. Ils répondront à vos besoins.

Spécialiste du bouchon en plastique, MOCAP est fabricant de bouchons de protection, MOCAP est fabricant, de bouchons en silicone. Le groupe vous propose l’achat et la vente de bouchons en plastique ainsi que toute une gamme de produits tels que la pastille haute température, le capuchon en vinyle et le ruban autosoudant.



Threaded Plastic Plugs for Straight Thread O-Ring Ports - Information

MOCAP Threaded Plastic Plugs are designed for use on Straight Thread O-Ring Ports. These Threaded Plastic Plugs are knurled for easy use in manual assembly and removal.

They provide positive seal on SAE Straight Thread O-Ring type ports and MIL-MS-33649 bosses. Integrated O-ring type bead seats in the bevel of the port to prevent entrance of debris or contaminants and oil leakage. Seal at outside of knurl protects port face against paint and dirt.

Our OPP Series Threaded Plugs are molded in Red polypropylene plastic and sized to fit Straight Thread O-Ring Ports from 7/16-20 thru 1-5/8-12.

MOCAP stocks Threaded Plastic Plugs for Straight Thread O-Ring Ports in many sizes for immediate shipment.

MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.
