Push-in Flange Protectors

MPI


Plastic Push-in Flange Protective Cover
MOCAP Plastic Push-in Flange Caps
  • Material: Low-Density Polyethylene (YELLOW)
  • Designed to Protect Flange Faces from Damage and Contamination
  • Flexible Rings Allow for Easy Installation

MPI – Media

Push-in Flange Protectors Plastic Push-in Flange Caps Plastic Protective Push-in Flange Plugs Plastic Push-in Flange Protective Cover Push-in Flange Protectors Push-in Flange Protectors Plastic Push-in Flange Protectors

Size Chart Plastic Push-in Flange Caps

PrintPrint

MPI Size Chart

Default Part # Description Product Line To Fit Nominal Pipe Size DIN Flange Size Diameter
in
mm
Flange OD
in
mm
Length
in
mm
Box/Mini/Micro
QTY
Buy Online
More info
Default Part # Description Product Line To Fit Nominal Pipe Size DIN Flange Size Diameter
in
mm
Flange OD
in
mm
Length
in
mm
Box/Mini/Micro
QTY
Buy Online
More info
1 MPI500YW1 1/2" NOMINAL SIZE PUSH-IN FLANGE PROTECTOR MPI 1/2" DN 15
0.748
19.0
3.543
90.0
0.591
15.0
1000 200 20
2 MPI750YW1 3/4" NOMINAL SIZE PUSH-IN FLANGE PROTECTOR MPI 3/4" DN 20
0.945
24.0
3.937
100.0
0.591
15.0
700 140 14
3 MPI1000YW1 1" NOMINAL SIZE PUSH-IN FLANGE PROTECTOR MPI 1" DN 25
1.181
30.0
4.331
110.0
0.787
20.0
500 100 10
4 MPI1250YW1 1-1/4" NOMINAL SIZE PUSH-IN FLANGE PROTECTOR MPI 1-1/4" DN 32
1.535
39.0
5.354
136.0
0.787
20.0
300 60 6
5 MPI1500YW1 1-1/2" NOMINAL SIZE PUSH-IN FLANGE PROTECTOR MPI 1-1/2" DN 40
1.772
45.0
5.748
146.0
0.787
20.0
250 50 5
6 MPI2000YW1 2" NOMINAL SIZE PUSH-IN FLANGE PROTECTOR MPI 2" DN 50
2.205
56.0
6.299
160.0
0.787
20.0
200 40 4
7 MPI2500YW1 2-1/2" NOMINAL SIZE PUSH-IN FLANGE PROTECTOR MPI 2-1/2" DN 65
2.835
72.0
7.087
180.0
0.787
20.0
200 40 4
8 MPI3000YW1 3" NOMINAL SIZE PUSH-IN FLANGE PROTECTOR MPI 3" DN 80
3.346
85.0
7.717
196.0
0.984
25.0
150 30 3
9 MPI4000YW1 4" NOMINAL SIZE PUSH-IN FLANGE PROTECTOR MPI 4" DN 100
4.291
109.0
8.504
216.0
0.984
25.0
100 20 2
10 MPI5000YW1 5" NOMINAL SIZE PUSH-IN FLANGE PROTECTOR MPI 5" DN 125
5.276
134.0
9.685
246.0
0.984
25.0
75 15 2
11 MPI6000YW1 6" NOMINAL SIZE PUSH-IN FLANGE PROTECTOR MPI 6" DN 150
6.339
161.0
11.023
280.0
1.378
35.0
40 8 1
12 MPI8000YW1 8" NOMINAL SIZE PUSH-IN FLANGE PROTECTOR MPI 8" DN 200
8.268
210.0
13.228
336.0
1.378
35.0
40 8 1
13 MPI10000YW1 10" NOMINAL SIZE PUSH-IN FLANGE PROTECTOR MPI 10" DN 250
10.315
262.0
15.354
390.0
1.575
40.0
28 5 1
14 MPI12000YW1 12" NOMINAL SIZE PUSH-IN FLANGE PROTECTOR MPI 12" DN 300
12.520
318.0
17.717
450.0
1.890
48.0
20 4 1
Legend:
- Add to Cart - View Price - Request Samples / More Info

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.
MOCAP vous propose la vente de capuchons de toutes sortes. Ils répondront à vos besoins.

Spécialiste du bouchon en plastique, MOCAP est fabricant de bouchons de protection, MOCAP est fabricant, de bouchons en silicone. Le groupe vous propose l’achat et la vente de bouchons en plastique ainsi que toute une gamme de produits tels que la pastille haute température, le capuchon en vinyle et le ruban autosoudant.



Push-in Flange Protectors - Information

MOCAP Push-In Flange Protectors are designed to fit many different styles and sizes of Flanges, allowing for for maximum flexibility. Designed to protect from damage and contamination during transit, handling and storage, our MPI series products are easy to install and remove.

Suitable for both imperial (ANSI) and metric (DIN) flanges to specifications DIN2627 - 2638, 150, BS 5504 and ANSIB16,5.
Our MPI Series Plugs are molded in Yellow polyethylene plastic to fit 1/2" thru 12" nominal sized pipe flanges.

MOCAP stocks Push-in Flange Protectors in many sizes for immediate shipment.
MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.





RoHS


Diagram
Plastic Push-in Flange Protectors
